Full Inkjet Coding Functions Multiple languages for user interface. Abundant character fonts, users can install all True Type font (.ttf) files to printers. Wide range of message objects: alphanumeric, date, time, logo, lot/ batch number, counter, shift code, barcode (including GS1 barcode), table grid, and external data. Various counter options. Automatically update manufacturing date, expiry date, time, shift code and external data. Plentiful formats of date/ time codes, or customer-made format. The “Side 1 = Side 2” function to apply one print template to two sides of a box at one time.

GS1 Compliance Barcodes Printing
Able to print various GS1 barcodes for global market.

Database Printing Using a database documenter to print out the designed print template with database objects. The database can be stored in the Dotjet printer’s memory in advance via a USB stick or conveying single data from a PC via a network.

MySQL Database Printing
Fetching data from a MySQL allows Dotjet inkjet printers to print respective database objects of a common MySQL database. This function can expand into various applications. Please contact Dotjet to learn more about it.

Remote Control
There is no need to walk to the site of production line to check printing status or to reload a print job. DotWare QT opens an access to fetch the printer’s operation screen, users can remotely monitor and operator the connected printers via a remote-desktop software.

 Protocol, Interface Commands Provided

Dotjet inkjet printers can receive printing protocols that are sent from an automatic centra system, printer servers or a host computer. This allows an external system to submit print jobs to a Dotjet inkjet printer and perform tasks such as querying the status of a printer, obtaining the status of print jobs, and canceling individual print job.

Using communication protocols that has utmost flexibility and expandability to help users comply with the track and trace regulations of different industries.

External Data Printing
When an external device conveys text string (ASCII) to the printer through serial ports, and/or the Ethernet , the DotWare QT provides the communication protocols to receive data and to output from the printhead.

Import .CSV Database File via Network
Ideal for coding products for track and trace requirements when multiple inkjet printers co-work for database printing. The database management in the central PC divides and exports database to respective printers. DotW QT software assigns a specific subfolder in the printer memory to store the database that is imported from the central PC via a network. When the database printing is completed, the imported database will be deleted automatically from the printer controller. The database printing with a network connection works more efficiently than manually copy the database file to individual printer via a USB stick.

Change Print Jobs by Commands from an External Device

By using an external device, such as a button, a photosensor, a barcode reader or a PC, Dotjet printers can make data output. The DotW QT has the features of making an index by external commands, automatically searching and opening a relative print file to instantly change the print template and the content. Please contact Dotjet for the details.

Directly Print Out the External Data in Text String
To prevent an entry error in a print message, using a barcode reader to change the print message content is a great solution. DotW QT can let printer print out the received data directly.

Integration with Dotjet CMD Software System

DotW QT is perfectly integrated into the Dotjet CMD Software System that is a revolutionary software to control, monitor, deliver data, and change print jobs via a remote PC or a smartphone. The Dotjet CMD Software System helps the supervisor manage all connected printers and the print jobs easily and efficiently.
